SMT Automatic Buffer Machine NGOK Buffer Equipment HXT-BF330 PCB Manufacturer With Best Price SMT
Stacker Cache Machine Single Rail and Double Raill Buffer with
Cooling Fan For PCB SMT Production Line
Description
Product name: Buffer Machine (with cooling fan and NGOK function):
Applicable to: It is used to sort out NG bad boards at the back of
the SMT production line inspection equipment, or it can be used as
a cache before and after equipment with a difference in working
speed.
Features:
*Strong and stable design
*PLC control system
*The control panel is LED true color touch screen
* With automatic alarm function
*Using double screw rods to rise and fall
*Standard equipped with signal, can be connected online with other
equipment
*Comprehensive multiple functions, first in first out, last in
first out, NG/OK and straight-through operation modes
*The touch screen of the equipment can identify the three states of
NG bad, OK and no board
* Dedicated wear-resistant stainless steel turnover box with
multi-layer conveyor belt
*The 120W motor drive makes the Magazine step up and down, and the
front and rear guide rods each maintain the balance of the storage
box
* Stepper motor transmission, precision ball screw
*Multi-layer W4 synchronous belt transmission, with two-layer
connection at the entrance
* Compatible with SMEMA interface
Product Specification
| Technical Parameters |
| PCB over half size: | Length (50-450)*Width (50-330) |
| Maximum capacity of circuit board: | 20-25 pieces (optional) |
| PCB board thickness: | Minimum 0.6mm |
| PCB thickness | Thinnest 0.4mm |
| Dimensions: | 500*1160*1700MM |
| Weight | Approx*190kg |
| Cycle Time | about 8 seconds |
| Teleport height | 920±20mm (customer specified) |
| Step selection | 1-4(25mm step) |
| Transmission direction: | Left → Right Right → Left (according to customer requirements) |
| Air pressure: | 4-6 bar, up to 10 l/min |
| Power supply and load: | 220V AC (customer specified), single phase, 250 VA max. |
Product details
Applications:
Widely used in electronics manufacturing, consumer electronics,
automobile electronics, communications equipment, aerospace,
medical equipment, LED lamps, computers and peripherals, smart
home, smart logistics, miniature and high power ratio electronic
devices.
